Calibration Charts			Case = ENRP_C2 ,  Cell  =  C2															05/31/05
								ENRP Cell 2
Simulation Period			08/01/94	12/31/98				Prior to STA1W construction
Output Period:			08/01/94	12/31/98
Calibration Period:			01/01/97	12/31/98
Predicted Values for Calibration Period						Calibration Set:		none		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			76	cm		K	23.5	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			5.4	cm/d		C1	22	ppb		Count		25	25	25	25	25	25
Mean P Load			1328	mg/m2-yr		C2	300	ppb		Observed		74.2	4.8	1.72	35.6	34.4	34.3	0.97
Mean Flow/Width			204	m2/day		Z1	40	cm		Predicted		76.4	4.8	1.68	35.1	34.9	34.5	1.00
Hydraulic Resid Time			14	days		Z2	0	cm		Mean Resid		-2.2	0.0	0.03	0.5	-0.5	-0.2	-0.03
Inflow Conc			68	ppb		Z3	0	cm		Bias %		-3%	1%	2%	1%	-1%	-1%	-3%
FWM Outflow Conc			35	ppb		Avg Int	30	days		Residual SE%		9%	11%	11%	27%	26%	26%
GeoMn Outflow Conc			35	ppb		Area	3.81	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
