Calibration Charts			Case = ENRP_C3 ,  Cell  =  C3															05/31/05
								ENRP Cell 3
Simulation Period			08/01/94	12/31/98				Prior to STA1W construction
Output Period:			08/01/94	12/31/98				Inflows include measured seepage return
Calibration Period:			01/01/97	12/31/98
Predicted Values for Calibration Period						Calibration Set:		none		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			35	cm		K	15.7	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			2.7	cm/d		C1	22	ppb		Count		25	25	25	25	25	25
Mean P Load			382	mg/m2-yr		C2	300	ppb		Observed		30.4	3.0	0.62	20.7	19.3	19.2	0.93
Mean Flow/Width			83	m2/day		Z1	40	cm		Predicted		35.3	2.5	0.48	19.3	19.4	19.6	1.01
Hydraulic Resid Time			13	days		Z2	0	cm		Mean Resid		-5.0	0.5	0.14	1.4	-0.1	-0.4	-0.08
Inflow Conc			39	ppb		Z3	0	cm		Bias %		-14%	21%	30%	7%	-1%	-2%	-7%
FWM Outflow Conc			19	ppb		Avg Int	30	days		Residual SE%		25%	31%	31%	47%	24%	24%
GeoMn Outflow Conc			19	ppb		Area	4.15	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
