Calibration Charts			Case = Lakeland ,  Cell  =  Lakeland_TMT															05/31/05
								High inlet P ~6000 ppb; clay soils; built on phosphate mine;
Simulation Period			01/01/93	09/30/99				poor hydraulics; used 10 iterations to stabilize biomass P
Output Period:			01/01/93	09/30/99				Qunits:
Calibration Period:			06/01/96	09/30/99
Predicted Values for Calibration Period						Calibration Set:		none		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			115	cm		K	14.6	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			0.7	cm/d		C1	22	ppb		Count		42	42	42	42	42	42
Mean P Load			12755	mg/m2-yr		C2	300	ppb		Observed		115.8	0.6	18.29	2907.9	2981.4	2972.2	1.03
Mean Flow/Width			18	m2/day		Z1	40	cm		Predicted		114.6	0.7	23.76	3171.2	3112.2	3155.7	0.98
Hydraulic Resid Time			154	days		Z2	0	cm		Mean Resid		1.3	-0.1	-5.47	-263.3	-130.8	-183.6	0.04
Inflow Conc			4696	ppb		Z3	0	cm		Bias %		1%	-16%	-23%	-8%	-4%	-6%	4%
FWM Outflow Conc			3171	ppb		Avg Int	30	days		Residual SE%		2%	47%	47%	93%	35%	35%
GeoMn Outflow Conc			3112	ppb		Area	4.8142	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
