Calibration Charts			Case = PSTA_FS2W ,  Cell  =  C2															05/31/05
								PSTA Field Scale Cell 2
Simulation Period			09/06/00	04/03/03				Limerock, Sinuous
Output Period:			07/01/01	04/03/03
Calibration Period:			08/01/02	04/03/03
Predicted Values for Calibration Period						Calibration Set:		none		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			29	cm		K	33.7	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			3%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			14.6	cm/d		C1	22	ppb		Count		35	36	36	36	36	36
Mean P Load			1447	mg/m2-yr		C2	300	ppb		Observed		30.0	8.9	1.08	12.2	12.1	12.0	0.99
Mean Flow/Width			132	m2/day		Z1	0	cm		Predicted		28.7	8.6	1.19	13.9	12.4	11.8	0.89
Hydraulic Resid Time			2	days		Z2	0	cm		Mean Resid		1.3	0.3	-0.11	-1.7	-0.3	0.2	0.10
Inflow Conc			27	ppb		Z3	0	cm		Bias %		4%	3%	-9%	-12%	-2%	2%	11%
FWM Outflow Conc			14	ppb		Avg Int	7	days		Residual SE%		18%	47%	41%	98%	39%	39%
GeoMn Outflow Conc			12	ppb		Area	0.02	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
