Calibration Charts			Case = PSTA_FS3W ,  Cell  =  C3															05/31/05
								PSTA Field Scale Cell 3
Simulation Period			09/06/00	04/03/03				scraped to caprock
Output Period:			07/01/01	04/03/03				with inflow & outflow seepage
Calibration Period:			08/01/02	04/03/03
Predicted Values for Calibration Period						Calibration Set:		none		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			35	cm		K	24.3	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			11.4	cm/d		C1	22	ppb		Count		36	36	36	36	36	36
Mean P Load			1168	mg/m2-yr		C2	300	ppb		Observed		35.9	12.7	1.90	15.0	14.6	14.6	0.97
Mean Flow/Width			33	m2/day		Z1	0	cm		Predicted		35.4	10.7	1.68	15.7	14.0	13.7	0.89
Hydraulic Resid Time			3	days		Z2	0	cm		Mean Resid		0.5	2.0	0.22	-0.7	0.6	0.9	0.08
Inflow Conc			28	ppb		Z3	0	cm		Bias %		1%	18%	13%	-4%	4%	6%	9%
FWM Outflow Conc			16	ppb		Avg Int	7	days		Residual SE%		10%	47%	42%	89%	28%	28%
GeoMn Outflow Conc			14	ppb		Area	0.0194	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
