Calibration Charts			Case = STA1W_All ,  Cell  =  ALL															05/31/05
								STA1W  - Full Operation - All Cells Combined
Simulation Period			08/01/94	03/31/05				Seepage Recycle Ignored
Output Period:			01/01/00	03/31/05
Calibration Period:			06/01/01	08/31/04
Predicted Values for Calibration Period						Calibration Set:		none		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			58	cm		K	34.0	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			5.0	cm/d		C1	22	ppb		Count		40	40	40	38	38	38
Mean P Load			2996	mg/m2-yr		C2	300	ppb		Observed		65.6	5.0	2.33	46.9	40.7	39.3	0.87
Mean Flow/Width			273	m2/day		Z1	40	cm		Predicted		58.0	4.4	1.97	45.0	39.4	36.5	0.87
Hydraulic Resid Time			12	days		Z2	0	cm		Mean Resid		7.6	0.6	0.35	1.9	1.3	2.8	-0.01
Inflow Conc			165	ppb		Z3	0	cm		Bias %		13%	13%	18%	4%	3%	8%	-1%
FWM Outflow Conc			45	ppb		Avg Int	30	days		Residual SE%		26%	24%	24%	59%	32%	32%
GeoMn Outflow Conc			39	ppb		Area	27	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
