Calibration Charts			Case = STA1W_C4 ,  Cell  =  C4															05/31/05
								STA1W - Cell 4
Simulation Period			08/01/94	03/31/05				Inflow = G254 - G309
Output Period:			01/01/00	03/31/05				Outflow = G256
Calibration Period:			07/01/00	08/31/04
Predicted Values for Calibration Period						Calibration Set:		none		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			62	cm		K	57.7	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			9.5	cm/d		C1	22	ppb		Count		51	51	51	49	49	49
Mean P Load			3485	mg/m2-yr		C2	300	ppb		Observed		66.4	9.0	3.38	37.5	32.0	32.2	0.85
Mean Flow/Width			162	m2/day		Z1	40	cm		Predicted		62.1	8.9	3.35	37.5	33.4	32.4	0.89
Hydraulic Resid Time			7	days		Z2	0	cm		Mean Resid		4.4	0.1	0.03	0.0	-1.4	-0.2	-0.04
Inflow Conc			100	ppb		Z3	0	cm		Bias %		7%	1%	1%	0%	-4%	0%	-4%
FWM Outflow Conc			38	ppb		Avg Int	30	days		Residual SE%		21%	26%	26%	177%	45%	45%
GeoMn Outflow Conc			33	ppb		Area	1.45	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
