Calibration Charts			Case = STA1W_C5AB ,  Cell  =  C5B															05/31/05
								STA1W - Cell 5 A & B
Simulation Period			08/01/94	03/31/05				Excluding post-hurricane period
Output Period:			01/01/00	03/31/05
Calibration Period:			07/01/02	08/31/04
Predicted Values for Calibration Period						Calibration Set:		none		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			67	cm		K	46.3	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			9.4	cm/d		C1	22	ppb		Count		27	27	27	26	26	26
Mean P Load			5279	mg/m2-yr		C2	300	ppb		Observed		65.5	9.6	5.45	56.7	55.4	56.2	0.98
Mean Flow/Width			374	m2/day		Z1	40	cm		Predicted		67.2	8.8	5.34	60.7	55.4	54.4	0.91
Hydraulic Resid Time			7	days		Z2	0	cm		Mean Resid		-1.7	0.8	0.10	-4.0	0.0	1.8	0.06
Inflow Conc			153	ppb		Z3	0	cm		Bias %		-3%	9%	2%	-7%	0%	3%	7%
FWM Outflow Conc			61	ppb		Avg Int	30	days		Residual SE%		28%	49%	49%	282%	39%	39%
GeoMn Outflow Conc			55	ppb		Area	9.279	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
