Calibration Charts			Case = STA2 ,  Cell  =  C3															05/31/05
								STA2 Cells in parallel
Simulation Period			03/01/01	03/24/05				Inflows  = S6 + G328 + Estimated Seepage to Inflow Canal
Output Period:			03/01/01	03/24/05
Calibration Period:			05/01/03	03/24/05
Predicted Values for Calibration Period						Calibration Set:		SAV_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			87	cm		K	52.5	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			5.0	cm/d		C1	22	ppb		Count		24	24	24	23	23	23
Mean P Load			1778	mg/m2-yr		C2	300	ppb		Observed		80.1	4.9	0.72	14.9	14.6	15.6	0.98
Mean Flow/Width			284	m2/day		Z1	40	cm		Predicted		87.3	4.8	0.87	18.0	11.2	9.9	0.63
Hydraulic Resid Time			18	days		Z2	100	cm		Mean Resid		-7.3	0.0	-0.14	-3.1	3.3	5.7	0.35
Inflow Conc			98	ppb		Z3	400	cm		Bias %		-8%	1%	-17%	-17%	30%	58%	57%
FWM Outflow Conc			18	ppb		Avg Int	30	days		Residual SE%		28%	24%	21%	158%	59%	59%
GeoMn Outflow Conc			11	ppb		Area	9.1911	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
