Calibration Charts			Case = STA2_C2 ,  Cell  =  C2															05/31/05
								STA2 - Cell 2
Simulation Period			03/01/01	03/24/05
Output Period:			03/01/01	03/24/05
Calibration Period:			05/01/03	03/24/05
Predicted Values for Calibration Period						Calibration Set:		none		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			66	cm		K	28.6	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			4.8	cm/d		C1	22	ppb		Count		24	24	24	24	24	24
Mean P Load			1919	mg/m2-yr		C2	300	ppb		Observed		64.7	4.5	1.29	28.5	21.0	19.6	0.74
Mean Flow/Width			276	m2/day		Z1	40	cm		Predicted		65.9	4.7	1.64	35.2	22.0	18.3	0.63
Hydraulic Resid Time			14	days		Z2	0	cm		Mean Resid		-1.2	-0.1	-0.35	-6.8	-1.1	1.3	0.11
Inflow Conc			110	ppb		Z3	0	cm		Bias %		-2%	-3%	-22%	-19%	-5%	7%	18%
FWM Outflow Conc			35	ppb		Avg Int	30	days		Residual SE%		21%	14%	14%	1875%	45%	45%
GeoMn Outflow Conc			22	ppb		Area	9.1911	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
