Calibration Charts			Case = STA5_C1AB ,  Cell  =  C1B															05/31/05
								STA5 Cells 1A & 1B in series
Simulation Period			06/01/99	02/28/05				inflows include measured seepage return
Output Period:			06/01/99	02/28/05
Calibration Period:			09/01/03	01/31/05
Predicted Values for Calibration Period						Calibration Set:		none		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			53	cm		K	17.7	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			6.1	cm/d		C1	22	ppb		Count		19	19	19	19	19	19
Mean P Load			2716	mg/m2-yr		C2	300	ppb		Observed		52.4	5.9	4.22	71.5	72.9	71.1	1.02
Mean Flow/Width			194	m2/day		Z1	40	cm		Predicted		53.1	5.7	4.36	76.9	71.4	70.1	0.93
Hydraulic Resid Time			9	days		Z2	0	cm		Mean Resid		-0.8	0.2	-0.14	-5.4	1.4	0.9	0.09
Inflow Conc			122	ppb		Z3	0	cm		Bias %		-1%	4%	-3%	-7%	2%	1%	10%
FWM Outflow Conc			77	ppb		Avg Int	30	days		Residual SE%		32%	26%	26%	175%	34%	34%
GeoMn Outflow Conc			71	ppb		Area	4.937	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
