Calibration Charts			Case = STA6_ALL ,  Cell  =  ALL															05/31/05
								STA6 Cells 3 & 5 Combined; driven gy G600
Simulation Period			12/01/97	01/24/05
Output Period:			12/01/97	01/24/05
Calibration Period:			07/01/00	01/24/05
Predicted Values for Calibration Period						Calibration Set:		none		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			48	cm		K	42.2	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			11%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			4.8	cm/d		C1	22	ppb		Count		57	49	49	48	48	48
Mean P Load			1436	mg/m2-yr		C2	300	ppb		Observed		48.0	3.7	0.78	21.3	18.1	18.5	0.85
Mean Flow/Width			90	m2/day		Z1	40	cm		Predicted		47.6	3.2	0.77	24.1	18.3	17.3	0.76
Hydraulic Resid Time			10	days		Z2	0	cm		Mean Resid		0.5	0.5	0.02	-2.8	-0.3	1.2	0.09
Inflow Conc			82	ppb		Z3	0	cm		Bias %		1%	15%	2%	-11%	-1%	7%	11%
FWM Outflow Conc			24	ppb		Avg Int	30	days		Residual SE%		9%	34%	38%	84%	43%	43%
GeoMn Outflow Conc			18	ppb		Area	3.5206	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
