Calibration Charts			Case = STA6_C3 ,  Cell  =  C3															05/31/05
								Cell 3 of STA 6
Simulation Period			12/01/97	01/24/05				Outflows monitored separately after July 2000
Output Period:			12/01/97	01/24/05
Calibration Period:			07/01/00	01/24/05
Predicted Values for Calibration Period						Calibration Set:		none		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			50	cm		K	48.6	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			9%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			6.9	cm/d		C1	22	ppb		Count		57	49	49	48	48	48
Mean P Load			1805	mg/m2-yr		C2	300	ppb		Observed		50.3	5.6	1.31	23.5	19.0	18.6	0.81
Mean Flow/Width			69	m2/day		Z1	40	cm		Predicted		50.0	5.6	1.28	23.1	19.6	18.9	0.85
Hydraulic Resid Time			7	days		Z2	0	cm		Mean Resid		0.3	0.0	0.03	0.4	-0.5	-0.4	-0.04
Inflow Conc			71	ppb		Z3	0	cm		Bias %		1%	1%	2%	2%	-3%	-2%	-5%
FWM Outflow Conc			23	ppb		Avg Int	30	days		Residual SE%		11%	46%	43%	95%	48%	48%
GeoMn Outflow Conc			20	ppb		Area	0.99	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
