Calibration Charts			Case = STA6_C5 ,  Cell  =  C5															05/31/05
								Cell 5 of STA 6
Simulation Period			12/01/97	01/20/05				Outflow monitored separated after july 2000
Output Period:			12/01/97	01/20/05
Calibration Period:			07/01/00	01/20/05
Predicted Values for Calibration Period						Calibration Set:		none		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			50	cm		K	34.9	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			4%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			3.4	cm/d		C1	22	ppb		Count		56	47	47	46	46	46
Mean P Load			972	mg/m2-yr		C2	300	ppb		Observed		47.2	3.1	0.61	19.8	16.5	16.7	0.83
Mean Flow/Width			71	m2/day		Z1	40	cm		Predicted		49.8	2.7	0.59	21.9	16.7	16.2	0.76
Hydraulic Resid Time			15	days		Z2	0	cm		Mean Resid		-2.7	0.4	0.02	-2.2	-0.2	0.4	0.07
Inflow Conc			79	ppb		Z3	0	cm		Bias %		-5%	14%	3%	-10%	-1%	3%	10%
FWM Outflow Conc			22	ppb		Avg Int	30	days		Residual SE%		12%	52%	54%	93%	46%	46%
GeoMn Outflow Conc			16	ppb		Area	2.5306	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
