Calibration Charts | Case = BoneyMarsh , Cell = Marsh | 05/31/05 | |||||||||||||||||
Boney Marsh | |||||||||||||||||||
Simulation Period | 03/27/76 | 12/31/85 | |||||||||||||||||
Output Period: | 04/01/79 | 12/31/85 | |||||||||||||||||
Calibration Period: | 01/01/82 | 12/31/85 | |||||||||||||||||
Predicted Values for Calibration Period | Calibration Set: | EMG_3 | Paired Observed & Predicted Values | FW | Not FW | GM / | |||||||||||||
Mean Depth | 46 | cm | K | 16.9 | m/yr | Depth | Flow | Load | FWM | GM | GM | FWM | |||||||
Frequency Z < 10 cm | 0% | C0 | 3.0 | ppb | cm | cm/d | mg/m2-d | ppb | ppb | ppb | - | ||||||||
Mean Hyd Load | 2.0 | cm/d | C1 | 22 | ppb | Count | 0 | 50 | 50 | 50 | 50 | 50 | |||||||
Mean P Load | 420 | mg/m2-yr | C2 | 300 | ppb | Observed | #N/A | 2.0 | 0.40 | 19.5 | 19.0 | 18.9 | 0.97 | ||||||
Mean Flow/Width | 32 | m2/day | Z1 | 40 | cm | Predicted | #N/A | 1.9 | 0.31 | 15.9 | 16.3 | 16.3 | 1.03 | ||||||
Hydraulic Resid Time | 23 | days | Z2 | 100 | cm | Mean Resid | #N/A | 0.1 | 0.09 | 3.7 | 2.7 | 2.7 | -0.05 | ||||||
Inflow Conc | 58 | ppb | Z3 | 400 | cm | Bias % | #N/A | 6% | 30% | 23% | 17% | 16% | -5% | ||||||
FWM Outflow Conc | 16 | ppb | Avg Int | 30 | days | Residual SE% | #N/A | 20% | 20% | 65% | 42% | 42% | |||||||
GeoMn Outflow Conc | 16 | ppb | Area | 0.4859 | km2 | ||||||||||||||
|
|||||||||||||||||||
green line on axis = calibration period | red symbols = observed | blue lines /symbols = predicted | Resid = observed - predicted, conc log-transformed |
