Calibration Charts			Case = C111_EAST ,  Cell  =  Marsh															05/31/05
								C111 - Periphyton Area - East Transect - Inflow from E1/W1
Simulation Period			01/01/95	12/31/00
Output Period:			01/01/97	12/31/00
Calibration Period:			09/01/98	12/31/00
Predicted Values for Calibration Period						Calibration Set:		PSTA_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			13	cm		K	23.6	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			38%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			8.8	cm/d		C1	22	ppb		Count		16	19	19	19	19	19
Mean P Load			230	mg/m2-yr		C2	300	ppb		Observed		7.8	12.9	0.92	7.2	5.4	5.2	0.75
Mean Flow/Width			53	m2/day		Z1	0	cm		Predicted		11.7	12.1	0.81	6.7	5.6	5.3	0.84
Hydraulic Resid Time			1	days		Z2	100	cm		Mean Resid		-3.9	0.8	0.12	0.5	-0.2	-0.2	-0.09
Inflow Conc			7	ppb		Z3	400	cm		Bias %		-33%	6%	15%	8%	-4%	-3%	-11%
FWM Outflow Conc			7	ppb		Avg Int	30	days		Residual SE%		60%	#N/A	19%	68%	41%	41%
GeoMn Outflow Conc			5	ppb		Area	3.7576	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
