Calibration Charts			Case = GEORGE ,  Cell  =  -															05/31/05
								mainstem st john's river; tp excursion 2001-2003 unexplained
Simulation Period			02/20/94	09/30/03				missing inflow data jan-july 2001
Output Period:			02/20/94	09/30/03
Calibration Period:			02/20/95	12/31/00
Predicted Values for Calibration Period						Calibration Set:		RES_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			341	cm		K	5.0	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			4.7	cm/d		C1	150	ppb		Count		72	72	72	72	72	72
Mean P Load			949	mg/m2-yr		C2	0	ppb		Observed		347.9	4.6	3.05	66.0	61.3	61.8	0.93
Mean Flow/Width			961	m2/day		Z1	40	cm		Predicted		341.3	4.8	2.56	53.9	53.2	53.2	0.99
Hydraulic Resid Time			73	days		Z2	100	cm		Mean Resid		6.6	-0.1	0.49	12.0	8.1	8.6	-0.06
Inflow Conc			56	ppb		Z3	400	cm		Bias %		2%	-3%	19%	22%	15%	16%	-6%
FWM Outflow Conc			54	ppb		Avg Int	30	days		Residual SE%		4%	24%	24%	48%	26%	26%
GeoMn Outflow Conc			53	ppb		Area	186.25	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
