Calibration Charts			Case = IronBridge ,  Cell  =  Marsh															05/31/05
								Orlando Easterly Wetlands / Iron Bridge; 1989-1997
Simulation Period			07/01/83	12/31/97				multi-cell treatment wetlands;  deep & shallow cells
Output Period:			07/01/88	12/31/97				excluding terminal lake
Calibration Period:			07/01/88	12/31/97
Predicted Values for Calibration Period						Calibration Set:		EMG_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			70	cm		K	16.9	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			1.1	cm/d		C1	22	ppb		Count		116	116	116	115	115	115
Mean P Load			1101	mg/m2-yr		C2	300	ppb		Observed		70.2	1.0	0.60	60.1	55.4	50.6	0.92
Mean Flow/Width			26	m2/day		Z1	40	cm		Predicted		70.4	1.1	0.61	56.7	54.5	54.4	0.96
Hydraulic Resid Time			66	days		Z2	100	cm		Mean Resid		-0.2	-0.1	-0.02	3.5	0.9	-3.8	-0.04
Inflow Conc			283	ppb		Z3	400	cm		Bias %		0%	-8%	-2%	6%	2%	-7%	-4%
FWM Outflow Conc			57	ppb		Avg Int	30	days		Residual SE%		0%	29%	29%	49%	24%	24%
GeoMn Outflow Conc			54	ppb		Area	4.8182	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
