Calibration Charts			Case = ISTOKPOGA ,  Cell  =  -															05/31/05
								data from Havens & Walker (2003)
Simulation Period			01/01/88	09/30/00
Output Period:			01/01/88	09/30/00
Calibration Period:			10/01/93	09/30/00
Predicted Values for Calibration Period						Calibration Set:		RES_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			159	cm		K	5.0	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			0.9	cm/d		C1	150	ppb		Count		29	29	29	28	28	28
Mean P Load			364	mg/m2-yr		C2	0	ppb		Observed		166.6	0.9	0.45	50.3	39.3	38.3	0.78
Mean Flow/Width			96	m2/day		Z1	40	cm		Predicted		158.9	0.9	0.44	50.0	44.5	44.2	0.89
Hydraulic Resid Time			170	days		Z2	100	cm		Mean Resid		7.7	0.0	0.01	0.3	-5.2	-5.9	-0.11
Inflow Conc			107	ppb		Z3	400	cm		Bias %		5%	1%	1%	1%	-12%	-13%	-12%
FWM Outflow Conc			50	ppb		Avg Int	90	days		Residual SE%		10%	36%	36%	185%	45%	45%
GeoMn Outflow Conc			45	ppb		Area	110	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
