Calibration Charts			Case = Lakeland ,  Cell  =  Lakeland_TMT															05/31/05
								High inlet P ~6000 ppb; clay soils; built on phosphate mine;
Simulation Period			01/01/93	09/30/99				poor hydraulics; used 10 iterations to stabilize biomass P
Output Period:			01/01/93	09/30/99				Qunits:
Calibration Period:			06/01/96	09/30/99
Predicted Values for Calibration Period						Calibration Set:		EMG_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			115	cm		K	16.9	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			0.7	cm/d		C1	22	ppb		Count		42	42	42	42	42	42
Mean P Load			12755	mg/m2-yr		C2	300	ppb		Observed		115.8	0.6	18.29	2907.9	2981.4	2972.2	1.03
Mean Flow/Width			18	m2/day		Z1	40	cm		Predicted		114.6	0.7	22.63	3020.8	2954.0	2994.0	0.98
Hydraulic Resid Time			154	days		Z2	100	cm		Mean Resid		1.3	-0.1	-4.35	-112.9	27.5	-21.8	0.05
Inflow Conc			4696	ppb		Z3	400	cm		Bias %		1%	-16%	-19%	-4%	1%	-1%	5%
FWM Outflow Conc			3021	ppb		Avg Int	30	days		Residual SE%		2%	47%	47%	92%	35%	35%
GeoMn Outflow Conc			2954	ppb		Area	4.8142	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
