Calibration Charts			Case = POINSETT ,  Cell  =  -															05/31/05
								depths estimated
Simulation Period			10/01/73	05/31/98				inflow P data sparse after 1990
Output Period:			10/01/73	05/31/98
Calibration Period:			10/01/74	09/30/90
Predicted Values for Calibration Period						Calibration Set:		RES_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			90	cm		K	5.0	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			10.8	cm/d		C1	150	ppb		Count		195	195	195	195	195	195
Mean P Load			3771	mg/m2-yr		C2	0	ppb		Observed		91.5	10.8	9.80	90.8	72.6	71.2	0.80
Mean Flow/Width			1025	m2/day		Z1	40	cm		Predicted		90.1	10.8	9.56	88.6	74.7	74.3	0.84
Hydraulic Resid Time			8	days		Z2	100	cm		Mean Resid		1.4	0.0	0.24	2.2	-2.1	-3.1	-0.04
Inflow Conc			95	ppb		Z3	400	cm		Bias %		2%	0%	3%	3%	-3%	-4%	-5%
FWM Outflow Conc			89	ppb		Avg Int	30	days		Residual SE%		14%	#N/A	0%	31%	31%	31%
GeoMn Outflow Conc			75	ppb		Area	17.54	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
