Calibration Charts			Case = PSTA_FS1W ,  Cell  =  C1															05/31/05
								PSTA Field Scale Cell 1
Simulation Period			09/06/00	04/03/03				Limerock
Output Period:			07/01/01	04/03/03
Calibration Period:			08/01/02	04/03/03
Predicted Values for Calibration Period						Calibration Set:		PSTA_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			40	cm		K	23.6	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			13.3	cm/d		C1	22	ppb		Count		35	36	36	35	35	35
Mean P Load			1278	mg/m2-yr		C2	300	ppb		Observed		38.1	6.4	1.18	18.4	17.3	17.5	0.94
Mean Flow/Width			39	m2/day		Z1	0	cm		Predicted		40.3	6.2	0.83	13.5	12.9	12.6	0.96
Hydraulic Resid Time			3	days		Z2	100	cm		Mean Resid		-2.1	0.3	0.35	4.9	4.4	4.9	-0.01
Inflow Conc			26	ppb		Z3	400	cm		Bias %		-5%	4%	42%	36%	34%	39%	-1%
FWM Outflow Conc			13	ppb		Avg Int	7	days		Residual SE%		17%	24%	15%	61%	43%	43%
GeoMn Outflow Conc			13	ppb		Area	0.0194	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
