Calibration Charts			Case = SAWGRASS ,  Cell  =  -															05/31/05
								Sawgrass Lake - SJWMCA
Simulation Period			03/01/96	09/30/99				compiled by WSI
Output Period:			03/01/96	09/30/99				short HRT
Calibration Period:			03/01/97	09/30/99
Predicted Values for Calibration Period						Calibration Set:		RES_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			134	cm		K	5.0	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			52.6	cm/d		C1	150	ppb		Count		32	32	32	32	32	32
Mean P Load			27487	mg/m2-yr		C2	0	ppb		Observed		158.0	52.5	64.93	123.8	136.3	133.2	1.10
Mean Flow/Width			1061	m2/day		Z1	40	cm		Predicted		133.5	52.5	72.68	138.5	149.8	148.1	1.08
Hydraulic Resid Time			3	days		Z2	100	cm		Mean Resid		24.5	0.0	-7.75	-14.8	-13.6	-14.8	0.02
Inflow Conc			143	ppb		Z3	400	cm		Bias %		18%	0%	-11%	-11%	-9%	-10%	2%
FWM Outflow Conc			139	ppb		Avg Int	30	days		Residual SE%		19%	#N/A	0%	26%	26%	26%
GeoMn Outflow Conc			150	ppb		Area	1.95	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
