Calibration Charts			Case = STA1W_C1 ,  Cell  =  C1															05/31/05
								STA1W - Cell 1; inflows include measured seepage return
Simulation Period			08/01/94	03/31/05
Output Period:			01/01/00	03/31/05
Calibration Period:			07/01/00	08/31/04
Predicted Values for Calibration Period						Calibration Set:		EMG_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			62	cm		K	16.9	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			4.6	cm/d		C1	22	ppb		Count		51	51	51	51	51	51
Mean P Load			2347	mg/m2-yr		C2	300	ppb		Observed		66.3	4.6	2.66	57.9	50.2	53.2	0.87
Mean Flow/Width			210	m2/day		Z1	40	cm		Predicted		61.7	4.2	2.68	64.3	55.6	51.7	0.86
Hydraulic Resid Time			13	days		Z2	100	cm		Mean Resid		4.6	0.4	-0.02	-6.4	-5.4	1.5	0.00
Inflow Conc			140	ppb		Z3	400	cm		Bias %		7%	10%	-1%	-10%	-10%	3%	0%
FWM Outflow Conc			64	ppb		Avg Int	30	days		Residual SE%		17%	45%	45%	71%	37%	37%
GeoMn Outflow Conc			56	ppb		Area	6.03	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
