Calibration Charts			Case = STA5_C2AB ,  Cell  =  2B															05/31/05
								STA5 Cells 2A & 2B
Simulation Period			06/01/99	02/28/05				Includes Measured Seepage Return at Inflow
Output Period:			06/01/99	02/28/05
Calibration Period:			09/01/03	02/28/05
Predicted Values for Calibration Period						Calibration Set:		EMG_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			34	cm		K	16.9	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			5%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			3.4	cm/d		C1	22	ppb		Count		19	19	19	17	17	17
Mean P Load			2567	mg/m2-yr		C2	300	ppb		Observed		36.9	2.5	3.36	134.0	104.3	111.7	0.78
Mean Flow/Width			109	m2/day		Z1	40	cm		Predicted		33.7	2.9	3.21	108.7	115.6	222.5	1.06
Hydraulic Resid Time			10	days		Z2	100	cm		Mean Resid		3.2	-0.4	0.15	25.4	-11.4	-110.8	-0.29
Inflow Conc			205	ppb		Z3	400	cm		Bias %		9%	-15%	5%	23%	-10%	-50%	-27%
FWM Outflow Conc			109	ppb		Avg Int	30	days		Residual SE%		46%	39%	39%	315%	44%	44%
GeoMn Outflow Conc			116	ppb		Area	4.937	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
