Calibration Charts			Case = STA1W_C13 ,  Cell  =  C3															06/01/05
								STA1W - Cell 1 & 3 ; inflows include measured seepage return
Simulation Period			08/01/94	03/31/05
Output Period:			01/01/00	03/31/05
Calibration Period:			07/01/00	08/31/04
Predicted Values for Calibration Period						Calibration Set:		EMG_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			43	cm		K	16.8	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			4%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			5.9	cm/d		C1	22	ppb		Count		51	51	51	47	47	47
Mean P Load			1400	mg/m2-yr		C2	300	ppb		Observed		46.2	4.9	2.00	40.3	32.9	31.7	0.82
Mean Flow/Width			180	m2/day		Z1	40	cm		Predicted		42.6	5.4	1.93	35.4	29.4	31.6	0.83
Hydraulic Resid Time			7	days		Z2	100	cm		Mean Resid		3.6	-0.5	0.07	4.9	3.5	0.1	-0.01
Inflow Conc			65	ppb		Z3	200	cm		Bias %		8%	-9%	3%	14%	12%	0%	-2%
FWM Outflow Conc			35	ppb		Avg Int	30	days		Residual SE%		28%	51%	51%	197%	41%	41%
GeoMn Outflow Conc			29	ppb		Area	4.15	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
