Calibration Charts			Case = STA1W_C24 ,  Cell  =  C4															06/01/05
								STA1W - Cell 2 & 4 in series
Simulation Period			08/01/94	03/31/05				G254 flows reduced by 20% after 2001 to close water budget (problems with UVM flow data)
Output Period:			01/01/00	03/31/05
Calibration Period:			07/01/00	08/31/04
Predicted Values for Calibration Period						Calibration Set:		SAV_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			60	cm		K	52.5	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			8%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			17.5	cm/d		C1	22	ppb		Count		51	51	51	51	51	51
Mean P Load			5888	mg/m2-yr		C2	300	ppb		Observed		66.4	17.2	9.76	56.8	37.1	35.7	0.65
Mean Flow/Width			297	m2/day		Z1	40	cm		Predicted		60.5	16.9	9.64	56.9	42.2	51.8	0.74
Hydraulic Resid Time			3	days		Z2	100	cm		Mean Resid		5.9	0.3	0.12	-0.1	-5.1	-16.1	-0.09
Inflow Conc			92	ppb		Z3	200	cm		Bias %		10%	2%	1%	0%	-12%	-31%	-12%
FWM Outflow Conc			57	ppb		Avg Int	30	days		Residual SE%		35%	33%	33%	74%	29%	29%
GeoMn Outflow Conc			42	ppb		Area	1.45	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
