Calibration Charts			Case = STA2_C1 ,  Cell  =  C1															06/01/05
								STA2 - Cell 1
Simulation Period			03/01/01	03/24/05
Output Period:			03/01/01	03/24/05
Calibration Period:			05/01/03	03/24/05
Predicted Values for Calibration Period						Calibration Set:		PEW_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			65	cm		K	34.9	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			0%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			3.0	cm/d		C1	22	ppb		Count		24	24	24	23	23	23
Mean P Load			1094	mg/m2-yr		C2	300	ppb		Observed		66.2	2.6	0.29	11.5	11.8	12.7	1.02
Mean Flow/Width			136	m2/day		Z1	40	cm		Predicted		65.5	2.9	0.44	15.3	11.6	9.7	0.76
Hydraulic Resid Time			22	days		Z2	100	cm		Mean Resid		0.8	-0.3	-0.15	-3.7	0.1	2.9	0.26
Inflow Conc			100	ppb		Z3	200	cm		Bias %		1%	-12%	-33%	-25%	1%	30%	34%
FWM Outflow Conc			15	ppb		Avg Int	30	days		Residual SE%		8%	27%	27%	109%	42%	42%
GeoMn Outflow Conc			12	ppb		Area	7.2881	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
