Calibration Charts			Case = STA34_C3 ,  Cell  =  3															06/01/05
								STA34 Cell 3
Simulation Period			10/01/03	03/31/05
Output Period:			10/01/03	03/31/05
Calibration Period:			04/01/04	03/31/05
Predicted Values for Calibration Period						Calibration Set:		EMG_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			40	cm		K	16.8	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			15%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			4.7	cm/d		C1	22	ppb		Count		5	6	6	6	6	6
Mean P Load			1302	mg/m2-yr		C2	300	ppb		Observed		5.0	15.2	1.74	11.4	11.8	12.1	1.04
Mean Flow/Width			169	m2/day		Z1	40	cm		Predicted		13.9	9.6	4.08	42.6	30.7	26.2	0.72
Hydraulic Resid Time			8	days		Z2	100	cm		Mean Resid		-8.9	5.6	-2.35	-31.2	-18.9	-14.2	0.32
Inflow Conc			76	ppb		Z3	200	cm		Bias %		-64%	59%	-57%	-73%	-61%	-54%	44%
FWM Outflow Conc			43	ppb		Avg Int	30	days		Residual SE%		69%	122%	84%	87%	106%	106%
GeoMn Outflow Conc			31	ppb		Area	12.298	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
