Calibration Charts			Case = STA6_C3 ,  Cell  =  C3															06/01/05
								Cell 3 of STA 6
Simulation Period			12/01/97	01/24/05				Outflows monitored separately after July 2000
Output Period:			12/01/97	01/24/05
Calibration Period:			07/01/00	01/24/05
Predicted Values for Calibration Period						Calibration Set:		PEW_3		Paired Observed & Predicted Values						FW	Not FW	GM /
Mean Depth			50	cm		K	34.9	m/yr				Depth	Flow	Load	FWM	GM	GM	FWM
Frequency Z < 10 cm			9%			C0	3.0	ppb				cm	cm/d	mg/m2-d	ppb	ppb	ppb	-
Mean Hyd Load			6.9	cm/d		C1	22	ppb		Count		57	49	49	48	48	48
Mean P Load			1805	mg/m2-yr		C2	300	ppb		Observed		50.3	5.6	1.31	23.5	19.0	18.6	0.81
Mean Flow/Width			69	m2/day		Z1	40	cm		Predicted		50.0	5.6	1.60	28.7	24.5	24.2	0.85
Hydraulic Resid Time			7	days		Z2	100	cm		Mean Resid		0.3	0.0	-0.28	-5.2	-5.5	-5.6	-0.04
Inflow Conc			71	ppb		Z3	200	cm		Bias %		1%	1%	-18%	-18%	-22%	-23%	-5%
FWM Outflow Conc			29	ppb		Avg Int	30	days		Residual SE%		11%	46%	43%	97%	53%	53%
GeoMn Outflow Conc			25	ppb		Area	0.99	km2
green line on axis  = calibration period					red symbols = observed				blue lines /symbols = predicted				Resid = observed - predicted,   conc log-transformed
